2DXV Series
When Sound Matters!
Power. Sound. Efficiency.
Take one get more. The 2DXV500 and 2DXV300 amplifiers are powerful, universal, ultra-compact tools for the most demanding applications. Designed and manufactured for the comfort of entertainment and information. And highest safety requirements.
Switchable 100/70 volts direct outputs, stereo or mono:
- 2x 300 W at 100 or 70 V (2DXV300)
- 2x 500 W at 100 or 70 V (2DXV500)
- 1x 600 W at 100 or 70 V or 8 ohms (2DXV300)
- 1x 1000 W at 100 or 70 V or 8 ohms (2DXV500)
Combined with a backup power supply of 24 V DC.
- Class D
- 100/70 volts direct output (switchable)
- 24 volts backup power
- Full continuous output power even during battery operation
- High power, high efficiency SMPS
- Efficiency > 80%
- Sleep Mode
- 70 Hz high pass filter, switchable
- Analog volume controls (at the back)
- Sequential remote power On/Off
- Alive contact
- DC and AC power-fail signalization
- LED indicators for POWER, SIGNAL, CLIP, PROTECT, AC POWER, DC POWER, SLEEP, MONO MODE
- Protection circuits for DC, LF, HF, Thermal, Short Circuit, Current Limiter
- Temperature controlled, variable speed, low noise fans
- Softstart
- Weight 13 kg
- Depth of chassis only 30 cm
- 3 years warranty
Technical Data
| 2DXV | ||||
| 300 | 500 | |||
| Channels | 2 | 2 | ||
| Class | D | D | ||
| Output Power per Chan. | W | 100 V | 300 | 500 |
| Frequency Response 100V | dB | 20 Hz | -0.6 | -0.6 |
| 20 kHz | -1.0 | -1.3 | ||
| Frequency Response 70V | dB | 20 Hz | -0.4 | -0.4 |
| 20 kHz | -1.5 | -2.2 | ||
| THD 1 kHz Full Power | % | < | 0.15 | 0.15 |
| Signal-to-Noise Ratio 20 Hz - 20 kHz | dB | > | 96 | 96 |
| Channel Separation | dB | > | 75 | 75 |
| Input Sensitivity | dBu | 0 | 0 | |
| Input Clipping | dBu | 21 | 21 | |
| Input Impedance | kΩ | 14 | 14 | |
| Voltage Gain | dB | 42 | 42 | |
| Cooling Fans (temperature controlled) | front | 0 | 0 | |
| back | 1 | 1 | ||
| Idle Current | A | 230 VAC | 0.3 | 0.3 |
| 24 VDC | 1.6 | 1.6 | ||
| Power Consumption 1/8 Load (Speech) | A | 100 V | 0.9 | 1.3 |
| 24 VDC | 5.5 | 8.8 | ||
| Power Consumption 1/3 Load (compr. Music) | A | 100 V | 1.8 | 3.0 |
| 24 VDC | 12.0 | 20.2 | ||
| Power Consumption Full Power | A | 100 V | 4.7 | 8.0 |
| 24 VDC | 33.0 | 53.0 | ||
| Heat Dissipation (Idle) | W* | 39 | 39 | |
| Heat Dissipation 1/8 Load (Speech) | W* | 100 V | 55 | 90 |
| Heat Dissipation 1/3 Load (compr. Music) | W* | 100 V | 85 | 150 |
| Heat Dissipation Full Power | W* | 100 V | 160 | 300 |
| DSP | no | |||
| SXL Dataport | no | |||
| Remote Power On | yes | |||
| Alive Contacts | 3 | |||
| Backup Power | 24 VDC | yes | ||
| Height | RU | 2 | 2 | |
| Depth | mm | 302 | 302 | |
| Weight (net) | kg | 13 | 13 | |
| Power Requirements | V | 210-240 | ||
| Hz | 50-60 | |||
