BASIC Series
No Compromises!
BASIC – that’s meeting the tightest budgets and professional requirements in reliability, flexibility and sound. Alone or in combination with the other products of the Bittner portfolio.
The consequent realisation of the Bittner quality standards indicates once more our understanding of the contracting business. It underlines our philosophy that cost consciousness has nothing to do with giving up standards. Compromise is a word unknown to Bittner Audio!
The incorporation of detent potentiometers, clip limiter, protection circuits for any imaginable situation, as well as a first-class production process using only highest-quality components made the BASIC series the choice of most contractors.
Certainly more than basic!
- High Tech SMT design
- Excellent sound and superior impulse response
- Protection Circuits: DC, LF, HF, Thermal, Short Circuit, Current Limiter, 3 ms Muting Delay
- XLR Inputs
- Speakon and Binding Posts
- Clip Limiter
- Toroidal transformers
- LED Indicators for SIGNAL, CLIP, PROTECT, POWER
- Temperature controlled, variable speed, low noise fans
- Detent potentiometers
- Stereo / Bridged / Parallel Mode
- Ground Lift
- Robust Steel Chassis
- 3 Year Warranty
Technical Data
| Basic | ||||||
| 200 | 400 | 800 | 1200 | |||
| Channels | 2 | 2 | 2 | 2 | ||
| Class | AB | AB | AB | AB | ||
| Burst per Channel 1 kHz | W | 8 Ω | 100 | 180 | 290 | 500 |
| 4 Ω | 130 | 250 | 490 | 840 | ||
| 2 Ω | --- | --- | --- | --- | ||
| Output Power per Chan. 20 Hz - 20 kHz 0.1% THD | W | 8 Ω | 80 | 125 | 230 | 380 |
| 4 Ω | 105 | 170 | 330 | 610 | ||
| 2 Ω | --- | --- | --- | --- | ||
| Output Power per Chan. 1 kHz / 1% THD | W | 8 Ω | 85 | 130 | 240 | 400 |
| 4 Ω | 115 | 180 | 350 | 650 | ||
| 2 Ω | --- | --- | --- | --- | ||
| Output Power bridged 20 Hz - 20 kHz 0.1% THD | W | 16 Ω | 160 | 250 | 460 | 760 |
| 8 Ω | 210 | 340 | 660 | 1220 | ||
| 4 Ω | --- | --- | --- | --- | ||
| Frequency Response Full Power | dB | 20 Hz | 0 | 0 | 0 | 0 |
| 20 kHz | -0.3 | -0.3 | -0.3 | -0.3 | ||
| THD 20 Hz - 20 kHz 10 dB below Full Power | % | < | 0.06 | 0.05 | 0.06 | 0.02 |
| THD 1 kHz Full Power | % | < | 0.08 | 0.06 | 0.08 | 0.05 |
| Signal-to-Noise Ratio 20 Hz - 20 kHz | dB | > | 102 | 103 | 103 | 103 |
| Channel Separation | dB | > | 85 | 85 | 85 | 85 |
| Input Sensitivity | dBu | -1 | 0 | +3 | +6 | |
| Input Clipping | dBu | 22 | 22 | 22 | 22 | |
| Input Impedance | kΩ | 20 | 20 | 20 | 20 | |
| Voltage Gain | dB | 28.8 | 31.4 | 34.1 | 36.4 | |
| Damping Factor | 4 Ω | 400 | 400 | 400 | 500 | |
| Cooling Fans (temperature controlled) | front | 0 | 0 | 0 | 0 | |
| back | 2 | 2 | 2 | 2 | ||
| Idle Current | A | 0.1 | 0.1 | 0.2 | 0.2 | |
| Power Consumption 1/8 Load (Speech) | A | 8 Ω | 0.7 | 1.1 | 1.8 | 2.8 |
| 4 Ω | 1.0 | 1.6 | 2.8 | 4.5 | ||
| 2 Ω | --- | --- | --- | --- | ||
| Power Consumption 1/3 Load (compressed Music) | A | 8 Ω | 1.0 | 1.6 | 2.7 | 4.2 |
| 4 Ω | 1.5 | 2.4 | 4.1 | 7.0 | ||
| 2 Ω | --- | --- | --- | --- | ||
| Power Consumption Full Power | A | 8 Ω | 1.6 | 2.5 | 4.2 | 6.8 |
| 4 Ω | 2.4 | 3.7 | 5.6 | 11 | ||
| 2 Ω | --- | --- | --- | --- | ||
| Heat Dissipation (Idle) | W | 12 | 17 | 22 | 22 | |
| Heat Dissipation 1/8 Load (Speech) | W | 8 Ω | 105 | 160 | 255 | 365 |
| 4 Ω | 150 | 245 | 425 | 660 | ||
| 2 Ω | --- | --- | --- | --- | ||
| Heat Dissipation 1/3 Load (compressed Music) | W | 8 Ω | 130 | 210 | 330 | 400 |
| 4 Ω | 230 | 340 | 600 | 770 | ||
| 2 Ω | --- | --- | --- | --- | ||
| Heat Dissipation Full Power | W | 8 Ω | 150 | 230 | 340 | 420 |
| 4 Ω | 280 | 410 | 640 | 800 | 2 Ω | --- | --- | --- | --- |
| DSP | no | |||||
| SXL Dataport | no | |||||
| Remote Power On | no | |||||
| Alive Contact | no | |||||
| Backup Power | 24 V DC | no | ||||
| Height | RU | 2 | 2 | 2 | 2 | |
| Depth | mm | 320 | 320 | 320 | 454 | |
| Weight (net) | kg | 10 | 12 | 13 | 15 | |
| Power Requirements | V | 210-240 | ||||
| Hz | 50-60 | |||||
